1 × HDMI 2.0 2 × USB 3.2 Gen 2 Type-A 1 × USB 3.2 Gen 2 Type-C (OTG) 2 × USB 2.0 Type-A 2 × RJ45 2 × 3.5 mm Audio Jacks
Interfaces/Ports
HDMI USB-A USB-C Gigabit Ethernet Audio In/Out MIPI CSI-2 GPIO UART I2C SPI CAN Bus
Expansion slots
1×M.2 2280 M Key PCIe Gen4×2 Slot ( with Pre-Installed 128GB SSD ) 1×M.2 2280/3080 M Key PCIe Gen4×4 Slot, Support SSD or Video Capture Cards 1×M.2 2230 E Key PCIe Gen4×1+USB2.0 Slot, Support WiFi Module. 1×M.2 3042/3052 B Key USB3.2 Gen1 Slot, Support 5G/4G Wireless Module.
LAN
2 × Gigabit Ethernet (10/100/1000 Mbps)
Wireless
Optional Wi-Fi via M.2 Module Optional 4G/5G Module
Bluetooth
Optional via Compatible Wireless Module
Built-in devices
NVIDIA Jetson Orin NX 16GB SoM 128 GB SSD
Camera
External MIPI CSI-2 Camera Support 8 Lanes D-PHY 2.1
Audio
1 × 3.5 mm Line In 1 × 3.5 mm Line Out I2S Interface
Power supply
DC Input: 12–36 V
Features
AI Performance: 157 TOPS Sparse / 78 TOPS Dense NVIDIA Ampere GPU Edge AI Computing 4 × M.2 Expansion Slots
Mechanical design
Compact Embedded AI Computer
Other
40-Pin Header 14-Pin Header Nano SIM Slot CAN Bus Firmware Upgradable Operating Temperature: 0–60°C with Airflow Storage Temperature: -20–80°C
1 × HDMI 2.0; 2 × USB 3.2 Gen 2 Type-A; 1 × USB 3.2 Gen 2 Type-C (OTG); 2 × USB 2.0 Type-A; 2 × RJ45; 2 × 3.5 mm Audio Jacks
Interfaces/Ports
HDMI; USB-A; USB-C; Gigabit Ethernet; Audio In/Out; MIPI CSI-2; GPIO; UART; I2C; SPI; CAN Bus
Expansion slots
1×M.2 2280 M Key PCIe Gen4×2 Slot ( with Pre-Installed 128GB SSD ); 1×M.2 2280/3080 M Key PCIe Gen4×4 Slot, Support SSD or Video Capture Cards; 1×M.2 2230 E Key PCIe Gen4×1+USB2.0 Slot, Support WiFi Module.; 1×M.2 3042/3052 B Key USB3.2 Gen1 Slot, Support 5G/4G Wireless Module.
LAN
2 × Gigabit Ethernet (10/100/1000 Mbps)
Wireless
Optional Wi-Fi via M.2 Module; Optional 4G/5G Module
Bluetooth
Optional via Compatible Wireless Module
Built-in devices
NVIDIA Jetson Orin NX 16GB SoM; 128 GB SSD
Camera
External MIPI CSI-2 Camera Support; 8 Lanes; D-PHY 2.1
Audio
1 × 3.5 mm Line In; 1 × 3.5 mm Line Out; I2S Interface
Power supply
DC Input: 12–36 V
Features
AI Performance: 157 TOPS Sparse / 78 TOPS Dense; NVIDIA Ampere GPU; Edge AI Computing; 4 × M.2 Expansion Slots
Mechanical design
Compact Embedded AI Computer
Other
40-Pin Header; 14-Pin Header; Nano SIM Slot; CAN Bus; Firmware Upgradable; Operating Temperature: 0–60°C with Airflow; Storage Temperature: -20–80°C
Weight
470 g
Dimensions
145 × 123 × 66 mm
От поръчката до готовата машина
След поръчката потвърждаваме наличността и срока по телефона.
Срок за доставка: 1–7 работни дни. Цената е крайна и е с включен ДДС.
При въпрос или необходимост от промяна се свързвате директно с GSOL, а не с анонимен външен склад.
