1x HDMI™ Support HDMI™ 2.1, maximum resolution of 4K 60Hz* 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz* *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed
CPU's supported
Supports Intel® Core™ Ultra Processors (Series 2)
Chipset
INTEL H810
Expansion slots
1x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset)
Storage
1x M.2 M.2_1 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G *Please refer to the manual for M.2 SSD heatsink restrictions.
Memory type
2x DDR5 UDIMM, Maximum Memory Capacity 128GB Memory Support DDR5 7200 - 4800 (JEDEC) MT/s Max. overclocking: • 1DPC 1R Max speed up to 7200 MT/s • 1DPC 2R Max speed up to 6400 MT/s Supports Intel® POR Speed and JEDEC Speed Supports Dual-Controller Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM
Rear panel I/O
DisplayPort USB 5Gbps Type-A USB 2.0 2.5G LAN Audio Connectors HDMITM USB 2.0
USB
4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) 1x USB 5Gbps Type C (Front)
Connectors
1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 5Gbps Type C ports
Audio
Realtek® ALC897 Codec 7.1-Channel High Definition Audio
Lan
Realtek® 8125D 2.5Gbps LAN
Form factor
mATX, 220mmx243.84mm
OS
Support for Windows® 11 64-bit
Other
4x EZ Debug LED 1x EZ Memory Detection LED
Гаранция
36 месеца
Марка
MSI
Manufacturer
MSI
Socket
LGA 1851
Graphics
1x HDMI™; Support HDMI™ 2.1, maximum resolution of 4K 60Hz*; 1x DisplayPort; Support DisplayPort 1.4, maximum resolution of 4K 60Hz*; *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed
CPU's supported
Supports Intel® Core™ Ultra Processors (Series 2)
Chipset
INTEL H810
Expansion slots
1x PCI-E x16 slot; 1x PCI-E x1 slot; PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU); PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset)
Storage
1x M.2; M.2_1 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices; 4x SATA 6G; *Please refer to the manual for M.2 SSD heatsink restrictions.
Memory type
2x DDR5 UDIMM, Maximum Memory Capacity 128GB; Memory Support DDR5 7200 - 4800 (JEDEC) MT/s; Max. overclocking:; • 1DPC 1R Max speed up to 7200 MT/s; • 1DPC 2R Max speed up to 6400 MT/s; Supports Intel® POR Speed and JEDEC Speed; Supports Dual-Controller Dual-Channel mode; Supports Non-ECC, Un-buffered memory; Supports CUDIMM
Rear panel I/O
DisplayPort; USB 5Gbps Type-A; USB 2.0; 2.5G LAN; Audio Connectors; HDMITM; USB 2.0
USB
4x USB 2.0 (Rear); 4x USB 2.0 (Front); 2x USB 5Gbps Type A (Rear); 2x USB 5Gbps Type A (Front); 1x USB 5Gbps Type C (Front)
Connectors
1x Power Connector(ATX_PWR); 1x Power Connector(CPU_PWR); 1x CPU Fan; 2x System Fan; 2x Front Panel (JFP); 1x Chassis Intrusion (JCI); 1x Front Audio (JAUD); 3x Addressable V2 RGB LED connector (JARGB_V2); 1x TPM pin header(Support TPM 2.0); 4x USB 2.0 ports; 2x USB 5Gbps Type A ports; 1x USB 5Gbps Type C ports
Audio
Realtek® ALC897 Codec; 7.1-Channel High Definition Audio
Lan
Realtek® 8125D 2.5Gbps LAN
Form factor
mATX, 220mmx243.84mm
OS
Support for Windows® 11 64-bit
Other
4x EZ Debug LED; 1x EZ Memory Detection LED
